Applications Technical Challenges and North American Compliance

LED lighting has reduced energy use during operation. The next opportunity lies in the materials used to make the product. Recycled polycarbonate, PC/ABS, ABS and polypropylene are increasingly considered for diffusers, housings, driver enclosures and internal components. Their use, however, requires more than a sustainability target. Each material must meet the optical, thermal, mechanical and safety demands of the finished luminaire.





Why lighting manufacturers are considering recycled plastics

Lighting companies are under growing pressure to reduce the use of virgin plastics and document progress against corporate sustainability goals. Introducing recycled content can lower reliance on fossil-based feedstock and support circular sourcing strategies without changing the basic manufacturing process.

The technical requirements vary widely by product. A residential ceiling light, an emergency luminaire and an outdoor area light operate at different temperatures and face different exposure conditions. Material selection therefore needs to begin with the component, the operating environment and the applicable safety standard.

Where recycled materials can be used

Component	Candidate material	Primary requirements	Main qualification risks
Transparent or diffusing cover	Recycled PC	Transmission, haze, impact resistance, colour stability	Contamination, black specks and long-term yellowing
Housing and rear cover	Recycled PC or PC/ABS	Heat resistance, flame rating, dimensional stability	Minimum wall thickness, local heat and brittle snap-fits
LED driver enclosure	Flame-retardant recycled PC or PC/ABS	Electrical insulation, heat and flame performance	Material recognition scope and actual temperature rise
Base and decorative parts	Recycled ABS or PP	Appearance, stiffness and moulding efficiency	Colour variation, shrinkage and finishing quality
Outdoor components	Weather-resistant recycled PC or PP	UV, moisture and temperature-cycle resistance	Long-term ageing and interaction with the sealing design

Five technical issues that determine whether a material is viable

1. Optical performance. A diffuser must deliver the specified light transmission and haze while maintaining uniform colour and appearance. Small amounts of mixed polymer, pigment or metal contamination can affect optical consistency. Transparent applications therefore require tighter feedstock selection and cleaning than opaque housings.

2. Heat and light ageing. LEDs are efficient, but the LED board, driver and heat sink still create local hot spots. Heat, blue light and ultraviolet exposure can cause yellowing, loss of transmission or embrittlement over time. Initial test results should be supported by ageing data that reflects the intended service conditions.

3. Flame performance and toughness. Flame-retardant additives, recycled content and flow modification can affect impact strength. The formulation has to meet the required flame rating without making clips, screw bosses or thin walls too brittle for assembly and field use.

4. Visible surface quality. Lighting reveals defects that may be less noticeable on other products. Flow marks, silver streaks, colour variation and black specks become more visible when the lamp is switched on. Dark, non-optical parts are often the most practical starting point for recycled content.

5. Outdoor durability. Outdoor luminaires face sunlight, water, temperature cycling, salt and airborne contaminants. Material weatherability must be assessed together with enclosure design, gaskets and drainage. A single UV test cannot establish the service life of the complete product.

What North American certification means for material selection

A plastic material recognition and a luminaire certification cover different levels of evaluation. UL 94 addresses the burning behaviour of polymeric materials. UL 1598 applies to luminaires, while ANSI/UL 8750 covers LED equipment used in lighting products. The standards that apply to a project depend on the product type, installation, environment and electrical design.

A flame rating does not certify the complete luminaire

The finished product is evaluated as a system. Wiring, spacings, the driver, temperature rise, mounting method, enclosure geometry and material properties all affect the result. A recognised material can simplify the review, but it does not replace product-level testing.

Thickness colour and formulation matter

A V-0 rating at 1.5 mm does not establish V-0 performance at 0.8 mm. Designers need to check the recognised minimum thickness, colour range and formulation against the production part. Changes to recycled feedstock, additive packages, colourants, recycled-content percentage or manufacturing site may require further review.

Operating temperature connects the material and the product design

Material data must be consistent with temperatures measured inside the luminaire. A higher-temperature resin cannot compensate for a poorly managed thermal path. The LED board, driver position, heat sink and ventilation strategy should be reviewed with the material choice.

Outdoor products require additional evidence

Polymeric materials used outdoors may need evaluation for ultraviolet and water exposure as part of the end-product assessment. UL 746C addresses polymeric materials used in electrical equipment and includes relevant environmental considerations. The certification body should confirm the exact test programme for the product and installation category.

A practical qualification route

1. Start with lower-risk parts. Introduce recycled content first in opaque decorative covers, bases or internal supports. Use production data from these parts before moving to diffusers or driver enclosures.

2. Write a component-level material specification. Define minimum wall thickness, flame rating, operating temperature, weatherability, colour, surface finish and mechanical requirements for each part.

3. Control feedstock and batch variation. Classify incoming feedstock, test critical properties, retain samples and lock the approved formulation. Recycled material needs a defined change-control process.

4. Test moulded parts under realistic conditions. Use production tooling to assess transmission, yellowing, drop performance, snap-fits, screw bosses, temperature rise and environmental cycling.

5. Review changes before production. Evaluate changes in feedstock source, recycled-content level, flame retardant, pigment, site or process before they enter a certified product.

6. Involve the material supplier early. Early coordination among the material supplier, moulder, luminaire designer and certification body reduces late-stage substitutions and repeated testing.

SUNYO supports recycled materials for demanding lighting applications

Recycled content becomes commercially useful when it can be specified, tested and produced consistently. SUNYO Carbon Reduction Recycle Material Co., Ltd. has spent three years developing and validating recycled PC formulations and has obtained a UL Yellow Card for its recycled PC material. This gives lighting manufacturers a clearer technical basis for material selection and product certification.

SUNYO is also an approved supplier to IKEA's lighting product group. The relationship reflects the practical requirements of international lighting supply chains, including material consistency, traceability and application support. SUNYO continues to work with lighting manufacturers on recycled engineering plastics that meet performance, processing and sustainability requirements in production.

References

• UL Standards and Engagement  UL 1598 Luminaires
• UL Standards and Engagement  ANSI UL 8750 LED Equipment for Use in Lighting Products
• UL Solutions  Recycled Plastics Testing and Certification
• UL Solutions  Understanding UL 94 Rating Certifications and Limitations
• IEC 60598 Series  Luminaires

This article is provided for general technical information. Applicable standards and test requirements should be confirmed for each product, market and construction with the relevant certification body.
